Data Mapper: Delivery Service Analogy

In most software projects, the way data is saved in a database is very different from how it is used inside your code. Databases organise data into tables and rows to save space and work fast, while your application uses objects with their own properties and methods. These two worlds rarely match up, making it tricky to connect them directly without causing confusion and maintenance headaches.

The Data Mapper pattern is the solution to this problem. It works as a special layer that translates data between your application and the database. This means your business logic stays clean, easy to test, and separate from database details. The Data Mapper is especially helpful for larger or more complex systems, as it keeps all the mapping rules in one place, making the whole application much easier to manage and update as your needs change.

Real-Life Analogy: Delivery Service Between Warehouse and Store

Imagine you own a local shop, but all your stock is stored far away in a big warehouse where products are packed in large crates for efficient storage. To keep your shop shelves organised for customers, you rely on a delivery service that fetches items from the warehouse, unpacks and rearranges them to suit your shop’s needs, and places them on the shelves. When something is sold or returned, the delivery service collects it from your shop, repackages it, and puts it back in the warehouse in the right crate.

• Warehouse: The database, where data is stored efficiently.
• Shop shelves: Application objects, arranged for easy use in your app.
• Delivery service: The Data Mapper, which moves and reshapes data between the two.

The delivery service (Data Mapper) manages all the back-and-forth. Your shop never worries about how the warehouse works, and the warehouse never needs to know how your shop is organised. Everything stays tidy, and each side can focus on what it does best.

Benefits of Data Mapper

Using the Data Mapper pattern has several important benefits, especially in larger systems or when you want to keep your codebase easy to maintain:

• Loose Coupling: Your business logic does not depend on the structure or details of your database.
• Better Testability: You can test your domain objects without a database connection.
• Centralised Mapping: All data conversion happens in one place, making it easier to update or change.
• Greater Flexibility: You can change your database structure or your objects independently.
• Cleaner Code: Keeps data access code out of your business logic, making everything easier to read and maintain.

What to Implement

To use the Data Mapper pattern, you usually create a mapper class for each object type you want to store. This mapper is responsible for converting between database rows and your domain objects, and vice versa. Your domain objects have no database logic inside them — all they do is hold data and behaviour. The mapper takes care of saving and loading them.

• Domain Objects: The main objects in your application, focused on business rules and logic.
• Data Mapper: A class (or set of classes) that transfers data between domain objects and the database, handling all mapping rules.
• Database Access Layer: The code that communicates directly with the database, such as SQL or ORM code.

How It Works in C#

Here is a simple example in C#. Let's say you have a Product object that you want to save and load from a SQL database, but you don't want any SQL code inside the Product class itself:

public class Product
{
    public int Id { get; set; }
    public string Name { get; set; }
    public decimal Price { get; set; }
}

public interface IProductMapper
{
    Product Find(int id);
    void Insert(Product product);
    void Update(Product product);
    void Delete(int id);
}

public class ProductMapper : IProductMapper
{
    private readonly string _connectionString;
    public ProductMapper(string connectionString)
    {
        _connectionString = connectionString;
    }

    public Product Find(int id)
    {
        // Pseudo-code: load product from database and map to object
        // In real code, use SqlConnection and SqlCommand
        return new Product { Id = id, Name = "Sample", Price = 9.99m };
    }

    public void Insert(Product product)
    {
        // Pseudo-code: insert product into database
    }

    public void Update(Product product)
    {
        // Pseudo-code: update product in database
    }

    public void Delete(int id)
    {
        // Pseudo-code: delete product from database
    }
}


In this setup, Product is a clean domain object with no database knowledge, and ProductMapper handles all the work of saving and loading.

When Should You Use It?

The Data Mapper pattern is a good choice when your application has a complex domain model, when your objects don't map directly to database tables, or when you want to keep your business logic and data access layers independent. It's also helpful if you want to test your domain objects without needing a real database, or if you want to support different databases or data sources in the future.

• Your application has a complex domain model or business rules.
• You need to support different storage formats or multiple databases.
• You want to be able to test your business logic separately from your data access code.
• You want to keep your domain objects focused on business behaviour only.

When Not to Use It:
For small projects or when your objects match your database tables very closely, the Data Mapper pattern might be too much work. In these cases, simpler patterns like Active Record or direct queries may be more practical.

Where Is It Used in the Real World?

The Data Mapper pattern is widely used in large-scale enterprise systems and frameworks that need to keep business logic and data storage separate. Many Object-Relational Mapping (ORM) tools are based on this pattern, even if they add extra features.

• Enterprise applications built using Domain-Driven Design (DDD)
• Online shopping platforms with rich product catalogues and custom business logic
• Banking and finance software where strict data mapping and validation are needed
• Popular frameworks like Doctrine (PHP), Hibernate (Java), and Entity Framework (C#)

Final Thoughts

The Data Mapper pattern is a powerful tool when you want to keep your code clean, testable, and easy to extend. While it takes more effort to set up compared to direct data access, it pays off in larger projects where flexibility and maintainability matter most.
