MVVM Pattern: Restaurant Tablet Ordering System

MVVM stands for Model-View-ViewModel. It's a software design pattern that helps organise code in applications where the user interface is separate from the business logic and data access. MVVM works well when the UI needs to update automatically as data changes.

This pattern splits your code into three parts: the View (what the user sees), the ViewModel (the logic that connects the UI to the data), and the Model (the actual data and business rules). In frameworks that support data binding, the View can automatically react when the ViewModel changes, and vice versa.

MVVM is especially helpful in XAML-based technologies like WPF and MAUI, where two-way binding and command support are built-in. It encourages clean architecture and testable code.

Real-Life Analogy: Restaurant Tablet Ordering System

Imagine you're at a restaurant with a tablet at your table. You use the tablet to pick food items, choose options like "extra cheese", and send your order — all without speaking to a waiter.

In this analogy:

• View = The tablet screen where you browse and tap
• ViewModel = The logic that reads your choices, formats them, and prepares them for the kitchen
• Model = The kitchen system where the actual order is stored and cooked

Benefits of MVVM

MVVM makes your app easier to maintain, test, and scale. Instead of writing code that manually updates the UI every time data changes, you use bindings between the View and ViewModel. Changes in one reflect in the other automatically.

It also separates concerns, so UI designers and developers can work in parallel — without interfering with each other's code.

• Two-way binding keeps UI and logic in sync
• Testable ViewModel without dependency on UI code
• Reusable logic across different Views
• Cleaner architecture by dividing responsibilities

What to Implement

The MVVM pattern includes:

• Model: Your domain data — classes like Order, Product, User
• ViewModel: Exposes bindable properties and commands
• View: XAML page or screen that binds to the ViewModel

How It Works in C#

// Model
public class MenuItem {
    public string Name { get; set; }
    public decimal Price { get; set; }
}

// ViewModel
public class OrderViewModel : INotifyPropertyChanged {
    private MenuItem _selectedItem;
    public MenuItem SelectedItem {
        get => _selectedItem;
        set {
            _selectedItem = value;
            OnPropertyChanged(nameof(SelectedItem));
        }
    }

    public ICommand PlaceOrderCommand { get; }

    public OrderViewModel() {
        PlaceOrderCommand = new RelayCommand(PlaceOrder);
    }

    private void PlaceOrder() {
        Console.WriteLine($"Order placed for: {_selectedItem.Name}");
    }

    public event PropertyChangedEventHandler PropertyChanged;
    protected void OnPropertyChanged(string name) {
        PropertyChanged?.Invoke(this, new PropertyChangedEventArgs(name));
    }
}

// View (WPF)
/*
<ComboBox ItemsSource="{Binding MenuItems}"
          SelectedItem="{Binding SelectedItem}" />

<Button Content="Place Order"
        Command="{Binding PlaceOrderCommand}" />
*/

When Should You Use It?

MVVM is a great choice when:

• You're building a WPF, MAUI, or Xamarin.Forms app
• Your UI is complex and must update as data changes
• You need to unit test your business logic without touching the UI
• You want to reuse logic across different screens or views

When Not to Use It: MVVM is not well suited for console apps, simple WinForms apps, or when data binding isn't available. In those cases, it adds complexity without real benefit.

Where Is MVVM Used in the Real World?

MVVM is mainly used in Microsoft technologies that support data binding. The pattern works best when the platform includes built-in support for binding, commands, and separation of UI logic.

• WPF desktop apps: Enterprise tools, dashboards, data-entry systems
• Xamarin.Forms apps: Cross-platform mobile apps sharing ViewModel logic
• .NET MAUI: Newer mobile and desktop apps using shared ViewModel code
• UWP/WinUI: Windows Store apps with XAML-based UI

Final Thoughts

MVVM is the go-to pattern for WPF and other XAML-based apps. It lets you build modern user interfaces that are cleanly separated from your logic and data.

Whether you're building a desktop admin panel, a mobile ordering app, or a kiosk UI, MVVM helps you manage changes, test behaviours, and scale your app with confidence.
